Dwyer 2-5001 Minihelic II Differential Pressure Gauge (0-1w.c)

It is our most compact gage but is easy to read and can safely operate at total pressures up to 30 psig. The Minihelic II gage is designed for panel mounting in a single 2-5/8 diameter hole. Standard pressure connections are barbed fittings for 3/16 ID tubing; optional 1/8 male NPT connections are also available. With removable lens and rear housing, the gage may be easily serviced at minimum cost. With the housing molded from mineral and glass filled nylon and the lens molded from acrylic, the gage will withstand rough use and exposure as well as high total pressure. The 5% accuracy and low cost of the Minihelic II gage make it well-suited for a wide variety of OEM and user applications. OEM applications include cabinet air purging, medical respiratory therapy equipment, air samplers, laminar flow hoods, and electronic air cooling systems. As an air filter gage, the Minihelic II gage finds many end use applications on large stationary engines, compressors, ventilators, and air handling units. The Minihelic II gage is suitable for many of the same applications as the Magnehelic gage where the greater accuracy, sensitivity, and higher and lower differential pressure ranges of the Magnehelic gage are not required. MANUFACTURER DIRECT Pressure Limits: 30 psig (2.067 bar) continuous to either pressure connection. Removable lens and rear-housing provides easy, cost-effective servicing Applications: Air Samplers, Filter Status, Medical Respiratory Eqpmnt, Room Positive Pressure Sensing, Electronic Air Cooling Sys, Duct Pressures
